Airtac HFK Guided Parallel Type Pneumatic Gripper HFK20R
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Guided Parallel Gripper HFK20R Technical Specifications
- Model: HFK20R
- Type: Guided parallel gripper (double-acting)
- Bore size: 20mm
- Stroke per jaw: 5mm standard (customizable)
- Operation mode: Bidirectional pneumatic drive
- Working pressure: 0.1-0.7 MPa
- Ambient temperature: -10℃ to +70℃
- Port size: M5x0.8 (1/8" NPT optional)
- Guide rail type: Dual linear ball bearings
- Repeat positioning accuracy: ±0.02mm
- Max gripping force: 32N @0.5MPa
- Body material: Anodized aluminum alloy
- Seal material: Polyurethane (NBR optional)
- Weight: 0.45kg ±3%
- Dimensions: 100mm(L) × 42mm(W) × 36mm(H)
- Shock resistance: 10G acceleration (30ms)
- Vibration resistance: 1.5mm amplitude @10-60Hz
The HFK20R precision guided gripper features dual linear ball bearings and hardened guide shafts for ultra-smooth operation, delivering exceptional positional repeatability even under high-speed cycling (up to 3 cycles/sec). Its compact design integrates dust-resistant seals and symmetrical air ports for flexible piping. Requires filtered air (5-40μm) with ISO VG32 lubricant or dry air operation.
- PCB component insertion machines
- Micro-motor shaft handling systems
- Optical lens assembly stations
- Pharmaceutical blister packaging
- Watch movement automation
- 3C product testing equipment
Mounting recommendation:
For vertical installations exceeding 2m/s² vibration, use anti-loosening screws
(M4×0.7, torque 1.2N·m) and align guide rails perpendicular to vibration axis.
Maintain 0.5mm minimum clearance between jaws and workpiece during homing.
| Property | Property Value |
|---|---|
| sku | HFK20R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Opening/Closing Stroke | <10mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
