Airtac HFK Guided Parallel Type Pneumatic Gripper HFK20W
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK20W Guided Parallel Pneumatic Gripper Specifications
- Model Series: HFK-W (Guided Parallel Type)
- Gripping Force: 20N at 0.5MPa
- Stroke per Finger: 5mm (Standard), 10mm optional
- Operating Pressure: 0.1-0.7 MPa
- Air Inlet: PT1/8 (M5x0.8 adapter included)
- Repeat Accuracy: ±0.05mm
- Guide Mechanism: Dual linear ball bearings
- Rail Material: Hardened steel with chromium plating
- Body Material: Anodized aluminum alloy
- Operating Temperature: -10℃ to 80℃
- Seal Type: NBR standard (FKM available for high temp)
- Protection Class: IP54 (dust/water resistant)
- Weight: 0.62kg ±3%
- Dimensions: 150mm(L) × 40mm(W) × 25mm(H)
Precision-guided parallel gripper featuring zero-backlash motion through dual linear guides and hardened steel rails. The HFK20W's twin piston design provides symmetrical gripping force distribution, with integrated shock absorption pads for delicate object handling. Requires filtered air (5-40μm) with optional position sensors for closed-loop control.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Watch movement handling systems
- Silicon wafer transfer robots
Maintenance tip:
Lubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid lateral torque exceeding 0.5Nm during operation. Maximum grip speed
should not surpass 500mm/s for optimal bearing life.
| Property | Property Value |
|---|---|
| sku | HFK20W |
| Gripper Optional Types | Side mount, narrow claw type |
| Opening/Closing Stroke | <10mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
