Airtac HFK Guided Parallel Type Pneumatic Gripper HFK25
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Gripper HFK25 Technical Details
- Model: HFK25 (Guided Parallel Type)
- Bore size: Ø25mm
- Stroke per jaw: 5mm (Standard), customizable up to 20mm
- Operating pressure: 0.1-0.7 MPa
- Max gripping force: 150N @0.6MPa
- Repeat accuracy: ±0.02mm
- Guide mechanism: Dual linear ball bearings
- Mounting pattern: 40×40mm square (ISO 9409-1 compatible)
- Port size: M5×0.8 (Dual ports for simultaneous actuation)
- Weight: 520g ±3% (Without accessories)
- Dimensions: 148mm(L) × 54mm(W) × 38mm(H)
- Material: Anodized aluminum body, hardened steel guide rods
- Seals: NBR standard (Optional FKM for high temp)
- Temperature range: -10℃ to 80℃ (Extended to 150℃ with FKM seals)
- Shock resistance: 50m/s² max
- Lubrication: Pre-lubed (Maintenance-free for 5,000km travel)
Precision-engineered parallel gripper with integrated linear guides, delivering exceptional rigidity and anti-torsion performance. The dual bearing system eliminates angular play during gripping operations, making it ideal for high-precision part handling. Features symmetrical air circuit design for balanced actuation force across both jaws.
- CNC machine tool loading/unloading systems
- Electronics PCB component insertion
- Medical device assembly with cleanroom compatibility
- Automotive fuel injector precision handling
- Optical lens positioning in manufacturing
Installation best practice:
Mount using M5×0.8 screws with 12N·m torque limit. For vertical installations,
use auxiliary support brackets to prevent guide rod deflection. Lubricate guide rails
every 2 million cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HFK25 |
| Gripper Optional Types | Standard Type |
| Opening/Closing Stroke | 14mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
