Airtac HFK Guided Parallel Type Pneumatic Gripper HFK25B
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK25B Guided Parallel Pneumatic Gripper Specifications
- Model: HFK25B
- Type: Double-acting guided parallel gripper
- Gripping force: 28-48N (adjustable via pressure)
- Stroke per jaw: 5mm
- Operating pressure: 0.1-0.7 MPa
- Guide rail type: Dual linear ball bearings
- Repeat accuracy: ±0.02mm
- Port size: M5 (1/8")
- Body material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Mounting options: Side/end mounting holes (M4×0.7)
- Weight: 0.32 kg
- Dimensions: 78mm(L) × 34mm(W) × 36mm(H)
Precision parallel gripper with integrated linear guides ensures smooth operation and high positional accuracy. Features adjustable gripping force through pressure regulation and dual ball bearing guidance for minimal play. Compatible with vacuum pads or custom jaws (2×M3 threaded holes per jaw). Requires 5μm filtered air with ISO VG32 hydraulic oil mist lubrication (1-2 drops/cycle recommended).
- PCB handling in SMT assembly lines
- Precision part positioning in CNC machine tending
- Medical device component assembly
- Automated sorting systems for small electronics
- 3C product manufacturing automation
Operational tip:
Maintain 0.05-0.15mm clearance between jaws and workpiece for optimal grip stability.
Lubricate guide rails every 500,000 cycles using specified grease (AIRTAC PG-01).
| Property | Property Value |
|---|---|
| sku | HFK25B |
| Gripper Optional Types | Side-mounted |
| Opening/Closing Stroke | 14mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
