Airtac HFK Guided Parallel Type Pneumatic Gripper HFK25M
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK25M Guided Parallel Pneumatic Gripper Specifications
- Model: HFK25M
- Type: Guided parallel gripper (dual-piston design)
- Gripping force: 32–240N adjustable (at 0.5MPa)
- Stroke per jaw: 5mm standard (customizable up to 20mm)
- Operating pressure: 0.2–0.7 MPa
- Port size: M5x0.8 (dual Rc1/8 ports for simultaneous actuation)
- Repeat accuracy: ±0.02mm
- Guide mechanism: Precision linear rails with 4 steel ball bearings
- Material: Aluminum alloy body, hardened steel jaws
- Temperature range: -10℃ to 80℃
- Weight: 340g (excluding accessories)
- Dimensions: 132mm(L) × 45mm(W) × 38mm(H)
- Max gripping speed: 150mm/s
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
- Shock resistance: 15G acceleration tolerance
The HFK25M features synchronized dual-piston actuation and hardened linear guides for precision gripping in high-cycle applications. Its T-slot jaw mounting system allows 360° tooling configuration. The anti-vibration design maintains positional accuracy even under 5Hz repeated impacts.
- Robotic PCB component insertion systems
- CNC machine tooling changeover arms
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Silicon wafer handling in cleanrooms
- High-speed sorting of metal fasteners
Operational note:
For maximum lifespan, use filtered air with 0.3μm filtration and maintain
0.1–0.3MPa higher pressure on return stroke during high-speed cycling.
Install shock absorbers when gripping masses over 1.2kg.
| Property | Property Value |
|---|---|
| sku | HFK25M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Opening/Closing Stroke | 14mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
