Airtac HFK Guided Parallel Type Pneumatic Gripper HFK25W
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK25W Guided Parallel Pneumatic Gripper Specifications
- Model: HFK25W
- Type: Guided parallel gripper (double-acting)
- Bore size: Ø25mm
- Operating pressure: 0.1-0.7 MPa
- Stroke range: 10-50mm (customizable)
- Gripping force: 60-350N (pressure-dependent)
- Repeat accuracy: ±0.05mm
- Guide type: Dual linear ball bearings
- Port size: M5x0.8 (1/8" NPT optional)
- Operating temperature: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Guide material: Hardened stainless steel
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54 (standard)/IP67 (optional)
- Lubrication: Pre-lubricated (maintenance-free)
- Response time: ≤0.1s (at 0.5MPa)
- Max sliding speed: 500mm/s
- Mounting: 4x M4 threaded holes (side/flange mounting)
- Weight: 650g ±3%
- Dimensions: 130mm(L) × 64mm(W) × 34mm(H)
Precision-guided parallel gripper with dual ball bearing slides for ultra-stable linear motion. Features zero-backlash design and wear-compensation mechanism, optimized for high-cycle automation tasks. Integrated T-slot on top surface allows modular tooling attachment. Compatible with vacuum cups/magnetic end effectors.
- PCB component insertion machines
- Robotic assembly of small mechanical parts
- Pharmaceutical blister packaging lines
- Optical lens handling systems
- 3C product testing equipment
- Precision gearbox assembly
Operation tip:
For maximum lifespan, maintain air filtration at 5μm or finer.
Use 0.3-0.5MPa for delicate operations, 0.7MPa for heavy gripping.
Align workpiece center within ±1mm of jaw midpoint.
| Property | Property Value |
|---|---|
| sku | HFK25W |
| Gripper Optional Types | Side mount, narrow claw type |
| Opening/Closing Stroke | 14mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
