Airtac HFK Guided Parallel Type Pneumatic Gripper HFK32
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Gripper HFK32 Technical Specifications
- Model: HFK32
- Type: Guided parallel pneumatic gripper (dual-axis guide)
- Gripping force: 32N @ 0.5MPa
- Operating pressure: 0.1–0.7 MPa
- Stroke per jaw: 10/15/20/25/30mm (configurable)
- Guide mechanism: Precision linear ball bearing slides
- Repeat accuracy: ±0.01mm
- Operating speed: 50-300mm/s (air pressure dependent)
- Port size: M5x0.8 (standard), G1/8 optional
- Material:
- Main body: Anodized aluminum alloy
- Guide rails: Hardened carbon steel
- Seals: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Weight: 1.2kg (base unit without accessories)
- Dimensions (L×W×H):
- Basic length: 100mm
- Width: 60mm
- Height: 40mm
- Total length with 30mm stroke: 130mm
Industrial-grade parallel gripper featuring twin linear guides for exceptional moment resistance and positional accuracy. The dual-cylinder design ensures synchronized jaw movement with minimal angular deviation (±0.1°). Optimized flow paths enable rapid response times (≤0.2s @ 0.5MPa). Includes adjustable mechanical stoppers and T-slot mounting surfaces.
- Precision component assembly in automotive manufacturing
- PCB handling in electronics production lines
- Bottle capping systems in packaging machinery
- Medical device manufacturing cleanrooms
- Robotic pick-and-place systems with payloads ≤5kg
Installation guidelines:
Use ISO 8573-1:2010 Class 3 compressed air with lubricator (recommended oil ISO VG32).
For vertical mounting, install exhaust mist separator. Maximum side load capacity: 15N·m.
Pre-lubricate guide rails every 500,000 cycles under continuous operation.
| Property | Property Value |
|---|---|
| sku | HFK32 |
| Gripper Optional Types | Standard Type |
| Opening/Closing Stroke | 22mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
