Airtac HFK Guided Parallel Type Pneumatic Gripper HFK32B
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Guided Parallel Pneumatic Gripper HFK32B Specifications
- Model: HFK32B
- Type: Guided parallel gripper (dual-action)
- Bore size: 32mm
- Stroke range: 20-100mm (customizable in 5mm increments)
- Operating pressure: 0.1–0.7 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Guide mechanism: Built-in linear guide rails
- Repeat positioning accuracy: ±0.05mm
- Drive method: Double-acting pneumatic
- Port size: PT1/8 (M5 optional)
- Seal material: Oil-resistant NBR
- Max gripping force: 56N @ 0.7MPa
- Speed range: 50-500mm/s (air cushion adjustable)
- Weight: 1.8kg (excluding accessories)
- Dimensions: 160mm(L) × 100mm(W) × 75mm(H) (standard stroke 50mm configuration)
- Rod end style: M6 threaded mounting holes (4x)
- Shock absorber: Built-in polyurethane cushioning
High-rigidity parallel gripper with integrated linear guides ensures precise parallel motion and exceptional moment resistance. Features anodized aluminum construction with hardened steel guide rails (HRC58+) for extended cycle life. The symmetrical design allows bi-directional mounting in automated systems. Requires 5μm filtered dry air with ISO VG32 lubrication recommended.
- CNC machine tool loading/unloading
- Precision gear assembly in automotive manufacturing
- PCB handling in electronics production lines
- Pharmaceutical blister packaging systems
- Robotic end-effector tool changing stations
Installation note:
Maintain 0.05mm maximum misalignment during mounting. Use precision shims if needed.
Lubricate guide rails every 500,000 cycles using lithium soap grease (NLGI #2 grade).
| Property | Property Value |
|---|---|
| sku | HFK32B |
| Gripper Optional Types | Side-mounted |
| Opening/Closing Stroke | 22mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
