Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL10N
$153.50
Regular price
$161.00
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFKL10N
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Pneumatic grippers (also known as pneumatic clamping jaws or pneumatic fingers) are compressed air-powered actuation devices designed for precise workpiece gripping and handling applications. Originally developed in Japan, these components have become essential in modern industrial automation systems.
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
Installation note:
Apply silicone-free lubricant (ISO VG32 grade) to guide rails every 50,000 cycles.
Use shock absorbers when stroke-end impact velocity exceeds 0.5m/s. Maintain 0.5mm
minimum clearance between jaws and workpiece during homing position calibration.
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
AirTAC HFKL10N Guided Parallel Pneumatic Gripper Specifications
- Model: HFKL10N (Rail-Guided Series)
- Gripper type: Parallel movement with integrated linear guide
- Bore size: Ø10mm
- Operating pressure: 0.1-0.7 MPa
- Max gripping force: 33N @ 0.5MPa
- Stroke per jaw: 0-4mm (adjustable)
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (Dual ports for push/pull action)
- Actuation: Double-acting
- Material: Aluminum alloy body, hardened steel guide rails
- Seals: NBR rubber (Oil-resistant)
- Temperature range: -10℃ to 80℃
- Weight: 250g ±5%
- Dimensions: 80mm(L) × 32mm(W) × 25mm(H)
- Mounting: 4x M3 threaded holes (6mm depth)
- Protection rating: IP54 (Dust protected, splash resistant)
Precision rail-guided gripper with zero backlash design, featuring hardened steel linear guides that enable smooth parallel motion and exceptional positional repeatability. The dual-port design allows for optimized air flow during both opening/closing cycles. Anti-vibration structure minimizes positional drift during high-speed operations.
Typical Applications:
- PCB component insertion machines
- Micro motor shaft handling systems
- Optical lens assembly stations
- Watch gear precision gripping
- 3C product testing equipment
Installation note:
Apply silicone-free lubricant (ISO VG32 grade) to guide rails every 50,000 cycles.
Use shock absorbers when stroke-end impact velocity exceeds 0.5m/s. Maintain 0.5mm
minimum clearance between jaws and workpiece during homing position calibration.
Dynamic Characteristics:
- Max operating speed: 500mm/s
- Cycle rate: 3 cycles/sec (full stroke)
- Startup friction: ≤1.5N
- Lifetime: 5,000km travel distance (under clean air supply)
| Property | Property Value |
|---|---|
| sku | HFKL10N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
