Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK10
- Type: Guided parallel gripper (dual-piston design)
- Gripping force: 10-180N adjustable (at 0.5MPa)
- Stroke per jaw: 0-6mm
- Guide rail size: 15mm width × 25mm height
- Repeat accuracy: ±0.02mm
- Operating pressure: 0.2-0.7 MPa
- Temperature range: -10℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54
- Weight: ~450g
- Dimensions: 125mm(L) × 52mm(W) × 40mm(H)
- Mounting: 4×M4 threaded holes (depth 6mm)
- Air connection: M5 × 0.8 dual ports
Precision guided gripper with hardened steel linear guides and dual piston drive mechanism, offering exceptional parallelism and anti-torsion stability. Features zero-backlash operation and wear compensation design, ideal for high-cycle automation environments. Requires 5μm filtered dry air with ISO VG32 lubricant.
- CNC machine tool part handling
- Precision electronic component assembly
- Pharmaceutical blister packaging systems
- Robotic arm end-effector integration
- Optical lens positioning devices
Installation note:
Maintain 0.05mm maximum misalignment during rail mounting. Apply lithium-based grease to guide rails every 500,000 cycles.
Use shock absorbers when gripping fragile materials.
- Parallel jaw movement with adjustable gripping force via pressure regulation
- Optional magnetic sensor slots for position feedback (M5 mounting)
- Customizable jaw face materials: Aluminum, POM, or silicone pads
- Maximum operating speed: 100mm/s (air cushioning recommended above 50mm/s)
| Property | Property Value |
|---|---|
| sku | HFSK10 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
