Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10B
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10B Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK10B
- Type: Guided parallel jaw gripper (dual-axis guide rail)
- Gripping force: 12-24N adjustable (at 0.5MPa)
- Stroke per jaw: 5mm
- Operating pressure: 0.15-0.7 MPa
- Rail type: Linear ball bearing guide
- Repeat accuracy: ±0.02mm
- Air inlet: M5×0.8 (dual ports for push/pull control)
- Weight: 0.28kg
- Dimensions: 80mm(L) × 34mm(W) × 42mm(H)
- Body material: Aluminum alloy (anodized surface)
- Jaw material: Stainless steel guide rails
- Temperature range: -10℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54
- Mounting holes: 2×M4 threaded (depth 5mm)
A precision parallel gripper with integrated linear guides, designed for high-accuracy part positioning and minimal moment load deflection. Features dual air ports for differential pressure control and anti-rotation mechanism. The T-slot jaw mounting surface allows custom finger tooling adaptation.
- PCB handling in SMT production lines
- Precision part insertion in robotic assembly
- Micro-component manipulation in watchmaking
- Automated sorting of small machined parts
- Laboratory sample handling systems
Operation note:
Requires 5-7μm filtered air. For optimal performance, lubricate guide rails with ISO VG32 turbine oil monthly.
Maximum lateral offset load: 0.5N·m. Avoid side impacts exceeding 15N.
- Use precision alignment jig (model AG-5H) for multi-gripper setups
- Maintain 0.3-0.5mm clearance between jaw faces and workpiece
- Install shock absorbers when cycle rate exceeds 120cpm
| Property | Property Value |
|---|---|
| sku | HFSK10B |
| Gripper Optional Types | Side-mounted |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
