Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10F
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10F Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK10F
- Type: Guided parallel gripper with linear slide mechanism
- Bore size: Φ10mm
- Operating pressure: 0.05–0.7 MPa
- Gripping force: 15–45N (adjustable via pressure)
- Stroke per jaw: 0–10mm
- Max jaw opening: 20mm
- Repeat accuracy: ±0.02mm
- Weight: 0.68kg
- Dimensions: 96mm(L) × 34mm(W) × 32mm(H)
- Slide rail type: Dual linear ball bearings
- Seal material: Polyurethane (PU) with wear-resistant coating
- Temperature range: -10℃ to 80℃
- Air port size: M5×0.8 (dual ports for push/pull operation)
- Mounting: 3×M4 threaded holes (T-slot compatible)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
Precision parallel gripper featuring dual-piston synchronization and hardened steel guide rails for smooth linear motion. The T-slot mounting surface allows multi-angle installation configurations. Optimized for high-speed applications requiring minimal maintenance, with corrosion-resistant aluminum alloy body and anti-vibration pads for shock absorption.
- High-speed pick-and-place in 3C electronics assembly lines
- Precision component insertion for PCB manufacturing
- Automated sorting systems for small mechanical parts
- Medical device assembly requiring contamination control
- Collaborative robot end-effector integration
Operational note:
For optimal performance, use filtered air (5-50μm) with lubricator (ISO VG32 oil mist).
Maximum recommended cycling speed: 3 cycles/second. Avoid lateral torque exceeding 0.5Nm.
| Property | Property Value |
|---|---|
| sku | HFSK10F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
