Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10M
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10M Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK10M
- Type: Parallel movement with integrated guide rail
- Gripping force: 15-20N (adjustable via pressure)
- Stroke per jaw: 6mm
- Operating pressure: 0.1-0.7 MPa
- Actuation: Double-acting (air required for both open/close)
- Guide rail type: Dual linear guide structure
- Repeat positioning accuracy: ±0.02mm
- Main body material: Anodized aluminum alloy
- Guide rail material: Hardened steel with chromium plating
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Port size: M5 (1/8")
- Weight: 0.45kg ±5%
- Dimensions: 75mm(L) × 34mm(W) × 32mm(H)
- Mounting pattern: 30mm × 22mm (2×M4 threaded holes)
- Max gripping speed: 100mm/s
- ISO certification: ISO 6432 compliant
Precision parallel gripper featuring hardened steel cross-roller guides for ultra-stable linear motion. Anti-vibration design maintains grip stability during high-speed operations. Includes adjustable stoppers for stroke limitation and shock-absorbing pads for silent operation (≤65dB). Compatible with vacuum suction cup adapters.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Watch movement handling systems
- 3C product testing equipment
Operational guidance:
Lubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
Maintain 0.3-0.5MPa air pressure for optimal service life. Install bypass
regulators for multi-gripper systems to prevent pressure drop interference.
Avoid lateral impact forces exceeding 30N.
Use 5-10μm precision filter regulator (AFR200 series recommended) to prevent
particle contamination in guide channels.
| Property | Property Value |
|---|---|
| sku | HFSK10M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
