Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10N
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10N Linear Guide Parallel Pneumatic Gripper Specifications
- Model: HFSK10N
- Type: Parallel jaw with integrated linear guide rail
- Gripping force: 45N (adjustable via pressure regulation)
- Max stroke per jaw: 10mm
- Operating pressure: 0.1-0.7 MPa
- Guide rail type: Dual-axis hardened steel with recirculating ball bearings
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for simultaneous actuation)
- Material: Aluminum alloy body with hard anodized surface
- Temperature range: -10℃ to 80℃
- Weight: 680g ±2%
- Dimensions: 116mm(L) × 48mm(W) × 38mm(H)
- Mounting pattern: 4x M4 threaded holes (depth 8mm)
- Shock resistance: 15G acceleration (10ms duration)
- Protection rating: IP54 (standard), IP67 optional
High-precision parallel gripper featuring integrated linear guides for ultra-stable part handling. The hardened steel rail system provides exceptional lateral stiffness (15N/μm rigidity) while maintaining smooth motion. Optimized flow channels enable 50ms open/close cycle times. Includes wear-compensation mechanism for long-term accuracy.
- PCB component insertion machines
- Automotive fuel injector assembly
- Precision bearing handling systems
- Pharmaceutical blister packaging
- Silicon wafer transfer robots
- Food-grade packaging (stainless steel version available)
Installation tip:
Apply lithium-based grease to guide rails every 500,000 cycles.
Use shock absorbers when gripping masses over 1.2kg to prevent
backlash. Maintain 0.3-0.5MPa air pressure for optimal seal life.
Critical note:
Avoid lateral impact forces exceeding 80N. Install protective
bellows (accessory HFSK-CV10) in environments with metal chips
or abrasive particles.
| Property | Property Value |
|---|---|
| sku | HFSK10N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
