Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK10W
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK10W Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK10W
- Type: Guided parallel gripper (dual rail structure)
- Gripping force: 25N @ 0.5MPa
- Stroke per jaw: 10mm
- Operating pressure: 0.1-0.7 MPa
- Rail type: Precision ground hardened steel guide
- Material: Aluminum alloy body with anti-corrosion treatment
- Seal material: NBR (Nitrile rubber)
- Port size: M5x0.8 pneumatic interface
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 70℃
- Weight: 420g ±5%
- Dimensions: 118mm(L) × 34mm(W) × 28mm(H)
- Max opening/closing speed: 100mm/s
- Mounting pattern: 30mm spaced M4 threaded holes
- Compatible rail systems: HSR15 series linear guides
- Protection rating: IP54
- Optional accessories: Shock absorber kit, position sensor brackets
High-precision parallel gripper with integrated linear guides for ultra-stable workpiece handling. Features zero-backlash rail mechanism and optimized air circuit design for smooth reciprocating motion. The hardened steel rails provide 2 million cycle durability under rated load. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality standard.
- Precision component assembly in semiconductor manufacturing
- CNC machine tool loading/unloading systems
- Micro-optical lens handling
- Medical device assembly lines
- High-speed sorting of electronic connectors
- Robotic pick-and-place for SMT components
Operation tip:
Maintain 0.3-0.5MPa initial pressure during installation alignment.
Apply lithium-based grease (NLGI #2) to guide rails every 50,000 cycles.
Use with AirTAC GRLA series regulators for optimal performance.
| Property | Property Value |
|---|---|
| sku | HFSK10W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
