Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK16B
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK16B Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK16B
- Type: Parallel guide rail type (double-acting)
- Clamping force: 120N (per finger at 0.5MPa)
- Stroke per finger: 20mm
- Operating pressure: 0.05–0.7 MPa
- Port size: M5x0.8 (Rc1/8 adaptor optional)
- Repeat positioning accuracy: ±0.05mm
- Main body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Temperature range: -10℃ to 80℃ (with NBR seals)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if needed)
- Max operating speed: 500mm/s
- Mounting hole pattern: 32mm × 22mm (M4 threaded)
- Weight: 650g ±3%
- Dimensions: 132mm(L) × 55mm(W) × 40mm(H)
High-precision parallel gripper with integrated linear guide rails for enhanced rigidity and anti-torsion capability. Features symmetrical force distribution and smooth motion characteristics through optimized air chamber design. The hardened guide rails enable stable gripping of both ferrous and non-ferrous workpieces.
- PCB board handling in electronics assembly
- Precision part positioning in CNC machine tending
- Carton box manipulation in packaging lines
- Medical device assembly with cleanroom compatibility
- Battery cell transfer in energy storage production
- Optical component handling in camera module assembly
Operational guidance:
Maintain 0.1-0.3MPa initial pressure during installation alignment.
Use 5-20μm filtered air with dew point -20℃ below ambient temperature.
For irregularly shaped objects, install custom jaw pads using the T-slot on finger surfaces (compatible with M3 fasteners).
| Property | Property Value |
|---|---|
| sku | HFSK16B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
