Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK16M
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK16M Guided Parallel Pneumatic Gripper Technical Details
- Model: HFSK16M
- Type: Guided parallel gripper (dual piston rod)
- Jaw stroke: 0-12mm (adjustable)
- Gripping force: 30N single finger / 60N dual fingers
- Operating pressure: 0.1-0.7 MPa
- Port size: M5 (1/8")
- Body material: Anodized aluminum alloy
- Rail type: Precision ground stainless steel guide
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Weight: 0.65kg ±3%
- Dimensions: 100mm(L) × 50mm(W) × 25mm(H)
- Protection rating: IP54 (standard) / IP67 (optional)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km operation)
High-precision parallel gripper with integrated linear guide rails, designed for precision part handling in confined spaces. Features zero-backlash jaw movement and anti-rotation mechanism for stable clamping. Optimized air passages enable 60ms open/close cycle time at 0.5MPa. Compatible with ISO 9400-1 mounting standards.
- Robotic arm end-effector tooling
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Micro-motor assembly systems
- Optical lens handling stations
Installation note:
Align guide rails parallel to workpiece axis during mounting.
Use M3x0.5 mounting screws with 0.45-0.55Nm torque.
Maintain air supply dew point 10℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | HFSK16M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
