Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK16N
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK16N Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK16N
- Type: Guided parallel gripper (dual-piston design)
- Guide rail type: Dual linear ball bearings
- Gripping force: 20-80N adjustable (at 0.5MPa)
- Max stroke: 16mm
- Operating pressure: 0.1-0.7 MPa
- Port size: M5 (1/8")
- Repeat positioning accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Temperature range: -20℃ to 80℃
- Weight: 520g ±2%
- Dimensions: 105mm(L) × 42mm(W) × 34mm(H)
- Mounting pattern: ISO 9409-1 compatible
- Max operating speed: 500mm/s
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
High-precision parallel gripper featuring wear-compensating guide rails and force feedback compatibility. The hardened steel rails provide 360° load distribution, enabling 10x longer service life than sleeve-guided models. Includes T-slot mounting surfaces and optional magnetic sensors (non-contact type recommended).
- Robotic pick-and-place systems (electronics assembly)
- CNC machine tooling changes
- Precision component inspection fixtures
- Pharmaceutical blister packaging
- Silicon wafer handling
- Automotive micro-part assembly
Operational guidance:
For optimal performance, maintain air supply dew point 15℃ below ambient temperature.
Use 2-position 5-way valve for speed control. Lubricate guide rails every 2 million cycles
using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | HFSK16N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
