Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK16R
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK16R Dual Rail Parallel Pneumatic Gripper Specifications
- Model: HFSK16R
- Type: Parallel movement with dual guide rails
- Gripping force: 16N (adjustable via pressure regulation)
- Stroke per jaw: 8mm standard (customizable)
- Operating pressure: 0.1-0.7 MPa
- Rail type: Linear ball bearing guide system
- Repeatability: ±0.02mm
- Bore size compatibility: Designed for φ16mm cylinders
- Port size: M5x0.8 (dual ports for push/pull action)
- Material: Anodized aluminum body, hardened steel rails
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (dust and splash resistant)
- Weight: 0.85kg (excluding accessories)
- Dimensions: 180mm(L) × 48mm(W) × 38mm(H)
Precision-engineered parallel gripper featuring dual linear guides for exceptional stability during high-speed operations. The hardened steel rails and preloaded ball bearings ensure minimal play and wear resistance. Optimized flow channels enable rapid response times (15ms open/close cycle at 0.5MPa). Includes T-slot mounting surfaces for flexible integration.
- High-speed pick-and-place in SMT component handling
- Precision alignment of optical components
- Medical device assembly requiring vibration-free clamping
- Robotic tool changing systems
- Cleanroom-compatible manufacturing processes
Operation tip:
For prolonged service life, maintain rail lubrication with ISO VG32-grade oil mist
and install external shock absorbers when handling payloads over 0.5kg at maximum speed.
- Custom jaw face materials (rubber, polyurethane, or Vespel®)
- Optional magnetic sensor slots for position feedback
- Reverse mounting capability for inverted installations
- High-temperature variant available (up to 120℃)
| Property | Property Value |
|---|---|
| sku | HFSK16R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
