Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20F
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20F Guided Parallel Pneumatic Gripper Technical Details
- Model: HFSK20F (Rail-Guided Parallel Type)
- Gripping force: 20N @ 0.5MPa
- Stroke per finger: 5mm (standard), customizable 2-15mm options
- Operating pressure: 0.1-0.7 MPa
- Port size: M5x0.8 dual air inlets
- Repeat positioning accuracy: ±0.02mm
- Guide rail type: Dual hardened aluminum with hard anodized surface
- Sliding material: Steel balls with self-lubricating bushings
- Seal material: NBR (Nitrile) with dust-resistant wipers
- Ambient temperature: -10℃ to 80℃
- Protection class: IP54 (standard), IP67 optional
- Weight: 520g ±5g (including rail system)
- Dimensions: 105mm(L) × 32mm(W) × 25mm(H) (finger unit only)
- Full assembly size: 145mm(L) × 45mm(W) × 38mm(H) (with mounting base)
Precision parallel gripper featuring dual-action piston mechanism with integrated T-slot rail guidance system. The hardened steel guide rails provide exceptional lateral stiffness (rated for 30N side load capacity), while the dual piston design ensures synchronized finger movement. Includes built-in cushioning adjustment screws for impact reduction at stroke ends.
- Robotic end-effectors for CNC machine tending
- Micro-component assembly in electronics manufacturing
- Medical device handling systems (cleanroom compatible)
- Precision part sorting with vision-guided robots
- Packaging line pick-and-place operations
Operation Tip:
For optimal performance, use filtered air (5-40μm) with 1-2 drops of ISO VG32 turbine oil per m³.
Maximum cycle rate: 3Hz continuous operation. Avoid lateral impact forces exceeding 50N during
workpiece misalignment scenarios.
- Base mounting: M4 threaded holes (4 places) with 30mm pitch
- Finger customization: Compatible with ISO 9409-1-50-4-M6 mounting pattern
- Air connection: 360° rotatable fittings for flexible plumbing
| Property | Property Value |
|---|---|
| sku | HFSK20F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
