Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20M
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20M Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK20M
- Type: Guided parallel gripper (double-acting)
- Gripping force: 180N @ 0.6MPa
- Stroke per jaw: 0-10mm (adjustable)
- Operating pressure: 0.1-0.7 MPa
- Port size: M5 × 0.8 (dual ports for parallel operation)
- Repeatability: ±0.02mm
- Guide mechanism: Dual linear ball bearings
- Body material: Anodized aluminum alloy
- Jaw material: Hardened stainless steel
- Operating temperature: -10℃ to 80℃
- Protection rating: IP54 (standard), IP67 optional
- Air consumption: 18.5cm³/stroke
- Weight: 680g ±2%
- Dimensions: 125mm(L) × 42mm(W) × 38mm(H)
Precision parallel gripper with integrated linear guides, engineered for high-speed automated handling. Features zero-backlash operation and anti-vibration design, maintaining positional accuracy through 10,000+ cycles. Self-lubricating bushings eliminate manual maintenance. Compatible with ISO9409-1 mounting patterns.
- Robotic arm end-effectors (6-axis/SCARA)
- PCB component insertion systems
- Pharmaceutical blister packaging lines
- Automotive micro-part assembly
- Optical lens positioning devices
Installation note:
Apply 0.5-0.7MPa dry air supply with 5μm filtration.
Use thread locker on mounting screws (M4×0.7, torque ≤1.2N·m).
For vacuum applications, specify optional silicone seals.
| Property | Property Value |
|---|---|
| sku | HFSK20M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
