Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK20N
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK20N Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK20N
- Type: Guided parallel gripper (dual-acting)
- Gripping force: 65N at 0.5MPa
- Stroke per jaw: 8mm (total 16mm opening)
- Operating pressure: 0.2–0.7 MPa
- Actuation method: Pneumatic (air pressure required)
- Guide rail type: Precision linear ball bearing
- Repeatability: ±0.02mm
- Port size: M5 (1/8")
- Body material: Anodized aluminum alloy
- Jaw material: Hardened stainless steel
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Weight: 0.65kg
- Dimensions: 116mm(L) × 60mm(W) × 28mm(H)
- Mounting pattern: ISO 9409-1 compliant
- Operating speed: 50-500mm/s (air pressure dependent)
High-precision parallel gripper with integrated linear guides, designed for ultra-stable part handling in automated systems. Features wear-resistant ceramic-coated guide rods and preloaded ball bearings for minimal play during high-speed operations. Requires dry compressed air (ISO 8573-1:2010 Class 3.4.2) with 20-30μm filtration.
- PCB component insertion machines
- Automotive assembly line part transfer
- Pharmaceutical blister packaging systems
- Robotic arm end-effector tooling
- Optical lens positioning devices
- Battery cell stacking automation
Operation tip:
For extended lifespan, maintain 0.1-0.3MPa lower pressure during homing position.
Lubricate guide rails every 500,000 cycles using ISO VG32 pneumatic tool oil.
- Multiple jaw face types available (V-groove, rubber pad, custom geometry)
- Optional magnetic sensor kits for position feedback (M9 connector)
- Reverse mounting capability for inverted installations
| Property | Property Value |
|---|---|
| sku | HFSK20N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
