Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25B
$203.29
Regular price
$210.79
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFSK25B
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Multiple bore sizes and specifications available, with diversified gripper types for selection.
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
Operation note:
For maximum service life, maintain air supply dew point below 3℃ and
install 5μm filter. Lubricate guide rails with ISO VG32 oil every
50,000 cycles in continuous operation.
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25B Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25B
- Type: Guided parallel gripper (dual sliding rail)
- Bore size: Ø25mm
- Max gripping force: 82N (at 0.6MPa)
- Stroke per jaw: 0-10mm (adjustable)
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, stainless steel guide rails
- Port size: M5×0.8 (dual ports for push/pull action)
- Repeat accuracy: ±0.01mm
- Max operating speed: 100mm/s
- Guide type: Dual linear ball bearing slides
- Mounting: 4×M4 threaded holes (bottom) + 2×M3 (side)
- Weight: 850g ±2%
- Dimensions: 155mm(L) × 58mm(W) × 30mm(H)
- Seal material: NBR (standard)/FKM (optional)
- Protection class: IP54 (standard)/IP67 (with optional seals)
Precision parallel gripper with hardened steel guide rails and anti-rotation mechanism, engineered for high-cycle automation tasks. Features dual air ports for optimized gripping/release response time (typical cycle time: 0.3s). The T-slot rail design allows direct mounting of tooling plates or force sensors.
Typical Applications:
- Robotic arm end-effectors for CNC machine tending
- Precision component assembly in electronics manufacturing
- Medical device handling systems
- Automated optical inspection (AOI) positioning
- Packaging line product sorting
- 3C industry component insertion
Operation note:
For maximum service life, maintain air supply dew point below 3℃ and
install 5μm filter. Lubricate guide rails with ISO VG32 oil every
50,000 cycles in continuous operation.
Mounting Configuration:
- Horizontal mounting recommended for heavy payloads
- Vertical mounting requires 20% force derating
- Use dynamic grip force calculator for variable payloads
- Compatible with ISO9409-1-50-4-M4 mounting pattern
| Property | Property Value |
|---|---|
| sku | HFSK25B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
