Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25F
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25F Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25F
- Type: Guided parallel gripper (twin-piston design)
- Structure material: Hard anodized aluminum alloy
- Drive method: Double-acting cylinder
- Gripping force: 25N (adjustable via pressure regulation)
- Guide mechanism: Linear ball bearing slide rails
- Stroke per jaw: 25mm (±12.5mm)
- Repeatability: ±0.02mm
- Port size: M5 (1/8")
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -10℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54
- Weight: 850g ±2%
- Dimensions: 140mm(L) × 65mm(W) × 35mm(H)
- Mounting pattern: 30mm × 60mm (ISO 9409-1 compatible)
- Max operating speed: 500mm/s
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
Precision parallel gripper with integrated linear guides and symmetrical force distribution, engineered for high-speed automated handling. Features zero-backlash ball bearing slides and T-slot mounting surfaces for accessory integration. Optimized for vertical/horizontal mounting with 360° adjustable pneumatic ports.
- PCB board handling in electronics assembly
- Precision part positioning in automotive engine assembly
- Bottle cap sorting systems in packaging machinery
- Medical device component transfer systems
- Robotic arm end-effector integration
- Silicon wafer handling in semiconductor manufacturing
Operational note:
Requires 40μm filtered air with ISO VG32 turbine oil mist lubrication (1 drop/m³).
For maximum service life, maintain 0.3-0.5 MPa operating pressure and avoid lateral
impact forces exceeding 150N during gripping operations.
| Property | Property Value |
|---|---|
| sku | HFSK25F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
