Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25M
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25M Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25M
- Type: Guided parallel gripper (dual-piston structure)
- Gripping force: 25N @0.5MPa
- Stroke per jaw: 10mm (total 20mm opening)
- Operating pressure: 0.15–0.7 MPa
- Port size: M5×0.8 (standard), G1/8 optional
- Material: Aluminum alloy body, steel guide rails
- Jaw material: Stainless steel (standard), PPS resin optional
- Repeat accuracy: ±0.05mm
- Temperature range: -10℃ to 70℃
- Weight: 520g ±5g
- Dimensions: 150mm(L) × 50mm(W) × 30mm(H)
- Seals: NBR standard, FKM optional
- Mounting: Dual linear guide rails with 4-row ball bearing system
- Shock resistance: 15m/s² max
- Protection rating: IP54 (standard), IP67 with optional kit
Precision parallel gripper featuring synchronized dual-piston actuation and hardened steel guide rails for ultra-stable gripping. Incorporates anti-vibration design with preloaded ball bearings, achieving 300,000km service life under rated load. Compatible with vacuum detection ports (optional) for suction-assisted handling.
- PCB component insertion machines
- Automotive fuel injector assembly lines
- Pharmaceutical blister packaging systems
- Precision bearing sorting automation
- 3C product testing equipment
Installation tip: Use precision alignment jigs during mounting - maximum allowable parallelism error ≤0.1mm/100mm.
Lubricate guide rails with ISO VG32 hydraulic oil every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | HFSK25M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
