Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25N
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25N Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25N
- Type: Guided parallel gripper (double-acting)
- Gripping force: 30-60N adjustable (at 0.5MPa)
- Stroke per jaw: 5mm standard (customizable to 10mm)
- Operating pressure: 0.1-0.7 MPa
- Bore size: Ø25mm
- Weight: 1.2kg ±5% (including rails)
- Dimensions: 150mm(L) × 54mm(W) × 38mm(H)
- Material: Anodized aluminum body, hardened steel guide rails
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for push/pull operation)
- Guide type: Dual linear ball bearings with preload adjustment
- Seal material: NBR standard (FKM available for high-temp)
- Operating temperature: -10℃ to 80℃ (NBR seals)
- Speed range: 50-500mm/s (air cushion adjustable)
- Shock resistance: 15m/s² max
- Protection rating: IP54 (IP67 with optional bellows)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if needed)
- Mounting: 4x M4 threaded holes (depth 8mm) on base
High-precision parallel gripper featuring dual hardened guide rails for moment load resistance and anti-rotation stability. The HFSK25N's T-slot jaw mounting system allows tooling customization while maintaining 5μm positional repeatability. Optimized flow paths enable rapid response (≤0.15s full stroke cycle). Includes built-in shock absorbers and dust-resistant wipers.
- CNC machine tool part loading/unloading
- PCB handling in SMT production lines
- Precision gear assembly systems
- Medical device component manipulation
- Automotive fuel injector testing fixtures
- Packaging line product orientation
Installation tip:
Maintain 0.02-0.05mm clearance between jaw tooling and workpiece.
Use synchronizing valves when operating multiple grippers.
Maximum side load: 15N at jaw tip (X/Y directions).
| Property | Property Value |
|---|---|
| sku | HFSK25N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
