Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25R
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25R Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25R
- Type: Guided parallel gripper (dual-action)
- Rail type: Precision-ground stainless steel linear guide
- Gripping force: 30N (single-acting) / 50N (double-acting)
- Stroke per jaw: 12.5mm (total 25mm opening)
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy (A6063-T5)
- Guide rail hardness: HRC 58-62
- Seal material: Oil-resistant NBR
- Port size: 1/8" NPT (M5 optional)
- Repeat accuracy: ±0.02mm
- Weight: 620g ±2%
- Dimensions: 160mm(L) × 40mm(W) × 35mm(H)
- Max sliding speed: 500mm/s
- Mounting pattern: ISO 9409-1 compliant
High-precision parallel gripper with integrated linear guides ensuring minimal deflection during operation. Features zero-backlash adjustment mechanism with graduated scale for jaw alignment. The dual-cylinder design provides symmetrical force distribution, making it ideal for delicate object handling. Compatible with ISO standard mounting systems and vacuum pads.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Micro-motor assembly lines
- Optical lens handling systems
- Semiconductor wafer transfer robots
- Precision gearbox manufacturing
Operation note:
Requires filtered air (5-50μm) with lubrication (ISO VG32 recommended).
For maximum precision, perform rail lubrication every 2 million cycles
using lithium-based grease. Avoid side-loading exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | HFSK25R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
