Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK25W
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK25W Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK25W
- Type: Guided parallel gripper (dual-piston structure)
- Bore size: Ø25mm
- Stroke per jaw: 0-12mm (adjustable)
- Operating pressure: 0.2-0.7 MPa
- Gripping force: 98N @0.5MPa
- Guide rail type: Dual linear ball bearings
- Port size: M5x0.8 (standard), G1/8 optional
- Repeat accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Jaw material: Stainless steel 304
- Temperature range: -10℃ to 80℃
- Weight: 750g ±3% (including guide rails)
- Dimensions: 145mm(L) × 50mm(W) × 42mm(H)
- Mounting pattern: ISO 9409-1-50-4-M6
- Air consumption: 28cm³/stroke @0.5MPa
Precision parallel gripper with integrated linear guides and wear-compensation mechanism, designed for high-cycle automation applications. Features zero-backlash operation through dual piston drive and hardened steel guide rails. Optional magnetic sensor slots (M5 mounting) for position feedback integration. Requires 5μm filtered dry air.
- CNC machine tool part loading/unloading
- PCB handling in SMT production lines
- Precision component assembly in automotive manufacturing
- Pharmaceutical blister pack handling
- Robotic end-effector tool changing systems
Installation note:
Apply 2Nm torque during rail mounting bolt tightening. Lubricate guide rails with ISO VG32 hydraulic oil
during initial installation. Maintain 0.1-0.3mm clearance between jaw tips and workpiece surface.
| Property | Property Value |
|---|---|
| sku | HFSK25W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
