Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK32
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK32 Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK32
- Type: Guided parallel jaw gripper (double-acting)
- Bore size: Ø32mm
- Operating pressure: 0.2–0.7 MPa
- Max stroke per jaw: 15mm
- Gripping force: 102N @0.5MPa
- Port size: M5 (1/8")
- Repeat accuracy: ±0.05mm
- Material: Aluminum alloy body, hardened steel guide rails
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.48kg (with guide rails)
- Dimensions: 164mm(L) × 82mm(W) × 50mm(H)
- Mounting pattern: ISO 9409-1-50-6-M6 (standard)
- Air consumption: 21.5cm³/stroke
- Response time: 50ms (open/close cycle)
- Protection rating: IP54
High-precision guided gripper with integrated linear guide rails for smooth parallel motion. Features wear-resistant anodized surface and dual piston design for balanced force distribution. Includes adjustable mechanical stoppers and mounting slots for position fine-tuning. Compatible with ISO standard gripper tooling plates.
- CNC machine tool part loading/unloading
- Electronics PCB handling systems
- Automotive component assembly lines
- Pharmaceutical blister packaging
- Robotic precision part sorting
Installation note:
Lubricate guide rails with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between jaws and workpiece during
gripping force adjustment. For optimal performance, use with
filtered air (5-40μm) and install silencers on exhaust ports.
- GRL32 series guide rail extensions
- AGS-M6 mounting brackets
- PSP-4 pressure sequence valve
- Jaw face kits: Rubber, Polyurethane, V-groove variants
| Property | Property Value |
|---|---|
| sku | HFSK32 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
| Stroke | 22mm |
