Airtac HFSK Guided Parallel Type Pneumatic Gripper HFSK40B
2. Integrated crossed roller linear guide structure provides superior strength, precision, and heavy-load capacity.
3. Positioned with bottom-located pins on linear guides to prevent misalignment between guide rail and main body.
4. Features: - Square-shaped sensor groove compatible with DS1G/CS1G sensors (no mounting accessories required) - Circular sensor groove compatible with DS1H sensor (tool-free installation) - Three-side mounting holes (side/bottom) for flexible installation configurations.
5. Precisely machined fixed reference pilot holes ensure positioning accuracy and repeatable assembly consistency during maintenance.
Category: Parallel Pneumatic Gripper | Brand: AIRTAC | Series: HFSK
AirTAC HFSK40B Guided Parallel Pneumatic Gripper Specifications
- Model: HFSK40B
- Type: Guided parallel gripper (dual-piston design)
- Gripping force: 250N (adjustable via pressure regulation)
- Stroke per jaw: 0-12mm (total opening 24mm)
- Operating pressure: 0.1-0.7 MPa
- Port size: M5 (1/8" NPT optional)
- Repeat accuracy: ±0.02mm
- Body material: Anodized aluminum alloy
- Guide rail type: Dual linear ball bearings
- Temperature range: -10℃ to 80℃
- Protection rating: IP54 (dust/water resistant)
- Mounting type: Through-hole mounting (4x M4 threads)
- Lead wire length: 2m standard (shielded cable)
- Voltage options: DC12V/24V (solenoid valve control)
- Weight: 1.8kg (including guides)
- Dimensions: 142mm(L) × 40mm(W) × 40mm(H)
High-rigidity parallel gripper with precision linear guides, engineered for stable gripping in high-cycle automation. Features anti-rotation mechanism and wear-compensating design with adjustable end cushioning. The integrated T-slot on the body allows modular accessory attachment. Requires 5-50μm filtered dry air.
- Robotic part handling in automotive assembly
- CNC machine tool loading/unloading systems
- Precision component sorting in electronics manufacturing
- Medical device assembly with clean room requirements
- Packaging line product orientation adjustment
Operation note:
Lubricate guide rails with ISO VG32 pneumatic oil monthly.
Maximum lateral offset load: 15% of gripping force.
For vertical installations, use auxiliary support brackets.
| Property | Property Value |
|---|---|
| sku | HFSK40B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <40mm> |
| Stroke | 30mm |
