Airtac HFSZ Guided Parallel Pneumatic Gripper HFSZ6B
1. Integrated linear guide design delivers exceptional rigidity and precision for stable operation;
2. Equipped with positioning dowel pins at guide base to prevent guideway-body misalignment;
3. Deepened reference centering holes on body enhance mounting accuracy and ensure consistent repositioning after repeated disassembly;
4. Customizable initial clamping position configuration available to meet diverse application scenarios.
Category: Parallel Pneumatic Grippers | Brand: AirTAC | Series: HFSZ
AirTAC HFSZ6B Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFSZ6B
- Type: Rail-guided parallel gripper (double-acting)
- Gripping force: 6N at 0.5MPa
- Stroke per finger: 2mm (standard), customizable up to 10mm
- Operating pressure: 0.1-0.7 MPa
- Port size: M5x0.8 (dual ports for simultaneous actuation)
- Guide mechanism: Dual linear ball bearings with preload adjustment
- Body material: Anodized aluminum alloy (A6063-T5)
- Sliding parts: Stainless steel (SUS304)
- Temperature range: -10℃ to 80℃
- Repeat accuracy: ±0.01mm
- Weight: 180g ±5g
- Dimensions: 64mm(L) × 34mm(W) × 25mm(H)
- Mounting: 4x M3 threaded holes (depth 5mm)
- Air consumption: 3.5cm³/stroke
- Lubrication: Pre-lubricated (Grease-free operation possible)
Precision parallel gripper with integrated linear guides, engineered for high-accuracy pick-and-place operations. Features zero-backlash motion through adjustable preload mechanism and symmetrical force distribution. Compatible with vacuum cups/magnetic ends via T-slot mounting. Requires 5μm filtered dry air.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Micro-motor shaft assembly lines
- Optical lens handling in cleanrooms
- Watch movement manufacturing
Operation note:
For precision tasks, maintain 0.3-0.5MPa operating pressure and perform
monthly rail lubrication with ISO VG32-grade oil. Avoid side-loading
during gripping operations.
- Stroke customization: 2/4/6/8/10mm variants
- Optional cushioning kits for high-speed applications
- ESD-safe version available (surface resistance 10⁶-10⁹Ω)
- High-temp variant (up to 120℃) with fluorocarbon seals
| Property | Property Value |
|---|---|
| sku | HFSZ6B |
| Gripper Optional Types | Side-mounted |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
