Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK10B
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK10B Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK10B
- Type: Guided parallel gripper (dual rail structure)
- Gripping force: 12-18N @ 0.5MPa
- Stroke per finger: 0-4mm
- Operating pressure: 0.1-0.7MPa
- Operation method: Double-acting
- Guide rail type: Linear ball bearing
- Repeat accuracy: ±0.01mm
- Bore size: Ø10mm
- Port size: M5×0.8
- Temperature range: -10℃ to 70℃
- Material: Aluminum alloy body, hardened steel guide rails
- Weight: 320g ±5g
- Dimensions: 62mm(L) × 40mm(W) × 32mm(H)
- Seal material: NBR (nitrile rubber)
- Shock resistance: 10m/s² max
- Vibration resistance: 1.5mm amplitude @ 10-60Hz
Precision-engineered parallel gripper with dual linear guides for ultra-stable part handling. Features zero-backlash ball bearing guidance and symmetrical force distribution, optimized for delicate component manipulation. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 standards.
- Micro-component assembly in electronics manufacturing
- PCB handling and placement systems
- Pharmaceutical blister packaging lines
- Watch movement assembly automation
- Optical lens sorting machines
- Medical device production (syringes, microfluidic chips)
Installation protocol: Mount using M3 screws (max torque 0.5Nm) on precision-machined surfaces (flatness ≤0.02mm). Lubricate guide rails with ISO VG32 hydraulic oil during maintenance. Avoid lateral impact forces exceeding 30N during operation.
- Cycle life: 10 million operations @ 2Hz frequency
- Max operating speed: 150mm/s
- Backdrive force: 50N (axial), 15N (radial)
- Position feedback: Optional magnetic sensor slots (2mm × 5mm groove)
| Property | Property Value |
|---|---|
| sku | HFTK10B |
| Gripper Optional Types | Side-mounted |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
