Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK10M
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK10M Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK10M
- Type: Guided parallel gripper (dual linear rail)
- Gripping force: 45N max @ 0.5MPa
- Stroke per jaw: 10mm
- Operating pressure: 0.05–0.7 MPa
- Port size: M5 (standard) / PT1/8 optional
- Repeat accuracy: ±0.02mm
- Rail type: Precision linear ball guide
- Body material: Anodized aluminum alloy
- Seal material: NBR rubber
- Temperature range: -10℃ to 80℃
- Protection rating: IP40
- Lubrication: Pre-lubricated (Grease retention structure)
- Mounting hole spacing: 40mm (horizontal) × 25mm (vertical)
- Compatible rails: SR/SRS series linear guides
- Max sliding speed: 500mm/s
- Service life: 5,000km (under rated conditions)
- Weight: 0.38kg
- Dimensions: 120mm(L) × 42mm(W) × 25mm(H)
Precision-guided parallel gripper featuring dual linear ball bearings for smooth operation and zero rotational deflection during clamping. The hardened guide rails and optimized jaw geometry ensure stable gripping of delicate or irregularly shaped objects. Includes built-in air cushioning adjustment ports for shock absorption at stroke ends.
- PCB handling in electronics assembly lines
- Precision component sorting in watch manufacturing
- Medical device component manipulation
- Automated packaging of small cosmetic containers
- 3C product testing equipment
Operation tip:
For fragile materials, reduce operating pressure to 0.1-0.3MPa and install
external flow control valves to achieve soft gripping. Maintain rail
lubrication every 500km of travel using ISO VG32-grade grease.
- Use SRS7LM or SR9WM series guides for heavy-duty cycles (>1 million actuations/year)
- Pair with APE10 series pressure regulators for force-sensitive applications
- Optional magnetic sensor slots (M5 mounting) available for position feedback
| Property | Property Value |
|---|---|
| sku | HFTK10M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
