Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK10N
$146.78
Regular price
$154.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFTK10N
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HFTK Guided Parallel Pneumatic Gripper
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
Installation note:
Use 0.3-0.5μm filtered air with 1-3 drops of ISO VG32 oil per m³.
Maintain 0.5mm minimum clearance between jaws and workpiece during homing position.
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK10N Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK10N
- Type: Guided parallel gripper (dual linear ball rail)
- Gripping force: 10N at 0.5MPa
- Stroke per finger: 4mm standard (2-12mm customizable)
- Operating pressure: 0.1-0.7 MPa
- Rail type: Precision ground linear ball guide
- Repeat accuracy: ±0.01mm
- Operating temperature: -10℃ to 80℃
- Port size: M5x0.8 (dual ports for push/pull action)
- Body material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Protection rating: IP54 (dust protected & splash resistant)
- Weight: 180g ±5g
- Dimensions: 60mm(L) × 34mm(W) × 25mm(H)
- Mounting pattern: 20mm square grid with M3 threaded holes
Precision-guided parallel gripper featuring dual linear ball bearings for smooth, zero-play operation. The hardened guide rails and optimized sealing structure ensure long-term stability in high-cycle applications. Includes built-in shock absorbers for soft landing control.
Typical Applications:
- PCB component insertion machines
- Micro-motor shaft assembly systems
- Pharmaceutical blister packaging lines
- Optical lens handling in cleanrooms
- 3C product testing equipment
Installation note:
Use 0.3-0.5μm filtered air with 1-3 drops of ISO VG32 oil per m³.
Maintain 0.5mm minimum clearance between jaws and workpiece during homing position.
Cycle Life:
2 million cycles (NBR seals) / 1.5 million cycles (PU seals) under
ISO 8573-1:2010 [4:4:3] air quality standards
| Property | Property Value |
|---|---|
| sku | HFTK10N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
