Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK10R
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK10R Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK10R
- Type: Parallel motion rail-guided gripper (double-acting)
- Gripping force: 20-35N adjustable (at 0.5MPa)
- Operating pressure: 0.2-0.7 MPa
- Guide rail type: Dual linear ball bearing system
- Stroke per jaw: 0-5mm (total opening range 0-10mm)
- Repeat accuracy: ±0.02mm
- Actuation: Air pressure via 2x M5 pneumatic ports
- Interface size: M5x0.8 threaded ports
- Main body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR rubber
- Temperature range: -5℃ to 80℃
- Weight: ~450g (including rails and mounting hardware)
- Dimensions: 68mm(L) × 42mm(W) × 25mm(H)
- Shock resistance: 10G acceleration (ISO 13732)
- Vibration resistance: 1.5mm amplitude @ 10-55Hz
Precision parallel gripper with integrated linear guides, designed for high-accuracy part handling. Features dual counter-opposed cylinders with synchronized movement and wear-compensating rail system. The hardened steel guide rails provide 0.01mm positional repeatability even after 5 million cycles. Includes mounting slots compatible with ISO 9409-1 pattern.
- CNC machine tool part loading/unloading
- Precision electronic component assembly
- Pharmaceutical blister pack handling
- Robotic end-effector integration (6-axis arms)
- Optical lens positioning systems
- Medical device manufacturing automation
Installation tip:
Use torque-controlled driver (0.8-1.2Nm) for rail mounting screws.
Lubricate guide rails with ISO VG32 hydraulic oil during maintenance.
Avoid lateral impact forces exceeding 50N during operation.
- Optimal response time: 0.15s @ 0.5MPa
- Max cycling rate: 120 cycles/minute (with 0.5s dwell time)
- Recommended air filtration: 5μm particulate filter
- Anti-stiction protocol: Exercise full stroke monthly if idle
| Property | Property Value |
|---|---|
| sku | HFTK10R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
