Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK10W
$146.78
Regular price
$154.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFTK10W
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HFTK Guided Parallel Pneumatic Gripper
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
Operation tip:
For precision tasks, maintain air pressure stability (±0.02MPa) and
use 5μm filtered dry air. Regular lubrication (every 50,000 cycles)
with ISO VG32 hydraulic oil extends rail life.
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK10W Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK10W
- Type: Guided parallel gripper with dual linear slides
- Gripping force: 20N (adjustable via pressure regulation)
- Stroke per finger: 15mm
- Operating pressure: 0.2–0.7 MPa
- Guide mechanism: Dual ball-bearing linear slides
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for push/pull action)
- Body material: Anodized aluminum alloy
- Slide rails: Hardened stainless steel
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Cycle life: 2 million operations (under standard conditions)
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 30mm(H)
Precision parallel gripper featuring synchronized dual-guide rail system for ultra-stable linear motion. Optimized for delicate part handling with anti-vibration structure and zero-backlash adjustment. Includes built-in T-slot for sensor mounting and optional position feedback.
Ideal Applications:
- High-speed PCB component insertion machines
- Pharmaceutical blister packaging systems
- Micro-motor shaft assembly lines
- Optical lens handling in cleanroom environments
- CNC machine tooling part exchange systems
Operation tip:
For precision tasks, maintain air pressure stability (±0.02MPa) and
use 5μm filtered dry air. Regular lubrication (every 50,000 cycles)
with ISO VG32 hydraulic oil extends rail life.
| Property | Property Value |
|---|---|
| sku | HFTK10W |
| Gripper Optional Types | Side mount, narrow claw type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
