Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK16
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK16 Guided Parallel Pneumatic Gripper Technical Details
- Model: HFTK16
- Type: Guided parallel gripper (double-acting)
- Bore size: 16mm
- Operating pressure: 0.2–0.7 MPa
- Stroke per jaw: 0–10mm (adjustable)
- Max gripping force: 88N @ 0.5MPa
- Repeat accuracy: ±0.02mm
- Guide mechanism: Dual linear ball bearings
- Body material: Anodized aluminum alloy
- Rail material: Stainless steel (SUS304)
- Seal type: NBR rubber seals
- Temperature range: -10℃ to 80℃
- Weight: 480g ±5%
- Dimensions: 96mm(L) × 44mm(W) × 32mm(H)
- Mounting pattern: 2×M4 threaded holes (8mm spacing)
- Air port size: M5×0.8 (standard), optional NPT1/8
Precision-engineered parallel gripper with integrated linear guides for smooth operation and zero rotational play. Features tool-free stroke adjustment via hex key and dual air ports for bidirectional control. Anti-corrosion coating makes it suitable for cleanroom environments (ISO Class 5 compliant). Includes built-in T-slot for sensor mounting.
- PCB handling in SMT assembly lines
- Precision part transfer in watch manufacturing
- Medical device component assembly
- Robotic pick-and-place systems (collaborative robots)
- Optical lens positioning systems
Operation tip:
For optimal performance, maintain air supply dew point ≤3℃ below ambient temperature.
Lubricate guide rails with ISO VG32 turbine oil every 50,000 cycles. Avoid side loads
exceeding 15N to prevent bearing wear.
| Property | Property Value |
|---|---|
| sku | HFTK16 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
