Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK16N
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK16N Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK16N
- Type: Guided parallel gripper (double-acting)
- Bore size: Ø16mm
- Operating pressure: 0.1-0.7 MPa
- Stroke options: 10/15/20/25/30mm (customizable)
- Gripping force: ~16N at 0.5 MPa
- Guide mechanism: Linear ball bearing rails
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, stainless steel guide rods
- Seals: NBR (standard), optional FKM for high temp
- Port size: M5x0.8
- Weight: ~350g (varies with stroke)
- Dimensions (L×W×H): 120mm × 50mm × 42mm (30mm stroke version)
- Mounting: Through-hole φ4.5mm × 2 or M4 threaded
- Max operating speed: 500mm/s
- IP rating: IP54 (standard), IP67 optional
Precision-guided parallel gripper with anti-rotation design, featuring hardened steel guide rails and pre-loaded ball bearings for smooth linear motion. The dual piston design ensures symmetrical gripping force distribution. Integrated T-slot on base allows modular tooling attachment. Compatible with vacuum cups or custom jaws (max jaw weight 100g).
- PCB handling in electronics assembly lines
- Precision part positioning in optical lens manufacturing
- Carton box manipulation in packaging systems
- CNC machine tool loading/unloading
- Medical device component assembly
Installation tips:
Maintain coaxial alignment between gripper and workpiece. Use adjustable stoppers (sold separately)
for stroke limitation. Lubricate guide rails every 500,000 cycles with ISO VG32 hydraulic oil.
Critical note:
Avoid side-load exceeding 15N during operation. For vertical mounting applications,
install an air pressure maintenance unit to prevent sudden drops.
| Property | Property Value |
|---|---|
| sku | HFTK16N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
