Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK25N
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK25N Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK25N
- Type: Guided parallel gripper (dual rail structure)
- Bore size: Ø25mm
- Stroke options: 10mm/15mm/20mm (customizable)
- Operating pressure: 0.1–0.7 MPa
- Max gripping force: 54N @0.5 MPa
- Rail type: Precision ground steel linear guides
- Repeat accuracy: ±0.02mm
- Port size: PT1/8 (G1/8 optional)
- Temperature range: -10℃ to 70℃
- Body material: Anodized aluminum alloy
- Seal material: Nitrile rubber (NBR)
- Mounting: Standard side mounting holes (M4×0.7)
- Protection rating: IP54
- Lubrication: Oil-free operation (oil mist compatible)
- Air consumption: 9.6cm³/stroke
- Air filtration: 40μm minimum
- Max sliding speed: 500mm/s
- Durability: 5 million cycles minimum
- Weight: 650g ±3%
- Dimensions (L×W×H): 128mm × 62mm × 42mm (closed position)
High-precision guided gripper with anti-rotation design, featuring hardened steel rails for smooth parallel motion. Optimized for precision part handling with integrated T-slot for sensor mounting. Includes built-in air cushioning adjustment for shock absorption during high-speed operation.
- PCB component insertion machines
- Automated syringe handling in medical devices
- Precision gear assembly in automotive manufacturing
- Silicon wafer transfer in semiconductor production
- High-speed packaging line item orientation
Operational note:
Maintain 0.3-0.5 MPa operating pressure for optimal grip force balance.
Regular rail lubrication (ISO VG32) recommended every 50,000 cycles
in continuous operation environments. Avoid lateral impact forces
exceeding 30N to maintain alignment accuracy.
| Property | Property Value |
|---|---|
| sku | HFTK25N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
