Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK25R
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK25R Guided Parallel Gripper Technical Details
- Model: HFTK25R
- Type: Guided parallel pneumatic gripper with linear slide rails
- Gripping force: 30-65N (adjustable via air pressure)
- Stroke per jaw: 0-12mm (total opening 24mm)
- Operating pressure: 0.15-0.7 MPa
- Guide mechanism: Dual linear ball bearings with hardened shafts
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (dual ports for push/pull operation)
- Body material: Anodized aluminum alloy (black oxide coating)
- Slide rail material: Stainless steel (SUS304)
- Temperature range: -10℃ to 80℃
- Weight: 280g ±5%
- Dimensions: 85mm(L) × 42mm(W) × 34mm(H)
- Mounting: 4x M4 threaded holes (depth 6mm)
- Max cycling rate: 3 cycles/second
- Air consumption: 4.5cm³/stroke (at 0.5MPa)
Precision parallel gripper featuring dual hardened linear guides for anti-rotation stability during high-speed operations. The through-hole piston design enables balanced force distribution, while the modular structure allows easy jaw customization. Includes built-in air cushioning adjustment for shock absorption at stroke ends.
- PCB component insertion machines
- Micro motor shaft assembly systems
- Watch component handling in horology automation
- Pharmaceutical blister packaging lines
- 3C product testing equipment (mobile phone components)
- Precision gear positioning in miniature robotics
Operation tip:
For precision gripping applications, use filtered air (5μm) and maintain 0.1-0.15MPa
lower pressure on release side during part ejection. Apply light machine oil (ISO VG32)
monthly to guide rails through lubrication ports.
- Standard jaw plates: 15mm contact width (replaceable)
- Optional vacuum cup adapter brackets
- Magnetic reed sensor ready (2.5mm slot for S-05 series)
- Compatible with AG series auto tool changers
| Property | Property Value |
|---|---|
| sku | HFTK25R |
| Gripper Optional Types | Wide-Narrow Claw Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
