Airtac HFTK Guided Parallel Type Pneumatic Gripper HFTK40B
$331.03
Regular price
$338.53
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFTK40B
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
HFTK Guided Parallel Pneumatic Gripper
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
Operational note:
Lubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid side-load forces exceeding 150N to maintain alignment accuracy.
1、Integrated linear guide structure ensures superior rigidity and precision;
2、Bottom-mounted positioning dowel pins on linear guide prevent misalignment between guide and main body;
3、Deepened reference centering holes on main body enhance mounting accuracy and maintain consistent positioning during repeated installation/dismantling;
4、Customizable initial gripper position accommodates diverse operational requirements under various working conditions.
Category: Parallel Pneumatic Grippers , Brand: AirTAC , Series: HFTK
AirTAC HFTK40B Guided Parallel Pneumatic Gripper Specifications
- Model: HFTK40B
- Type: Guided parallel gripper (double-acting)
- Bore size: Ø40mm
- Stroke per jaw: 0-12mm (adjustable)
- Operating pressure: 0.2-0.7 MPa
- Guide rail type: Linear ball bearing structure
- Repeat accuracy: ±0.02mm
- Gripping force: 210N @0.5MPa
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Weight: 1.2kg (including guide rails)
- Dimensions: 156mm(L) × 62mm(W) × 44mm(H)
- Mounting pattern: ISO 9409-1 compliant
- Shock resistance: 10G acceleration (30ms)
High-rigidity parallel gripper with integrated linear guides, designed for precision handling of medium-weight components. Features zero-backlash operation and adjustable stroke via mechanical stops. Optional magnetic sensor slots (M5 mounting) for position feedback integration.
Typical Applications:
- CNC machine tool loading/unloading systems
- Precision gear assembly in automotive manufacturing
- PCB board handling in electronics production lines
- Bottle cap positioning in pharmaceutical packaging
- Robotic welding fixture positioning
Operational note:
Lubricate guide rails every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid side-load forces exceeding 150N to maintain alignment accuracy.
| Property | Property Value |
|---|---|
| sku | HFTK40B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <40mm> |
| Stroke | 30mm |
