Airtac HFTKL Guided Parallel Type Pneumatic Gripper HFTKL10F
Type: Rail-Guided Parallel Pneumatic Gripper
Brand: AirTAC
Series: HFTKL
AirTAC HFTKL10F Guided Parallel Pneumatic Gripper Technical Details
- Model: HFTKL10F (Guided Parallel Type)
- Structure: Dual linear guide rail integrated
- Gripping force: 16-35N adjustable (air pressure dependent)
- Stroke per finger: 5mm standard
- Operating pressure: 0.05-0.7 MPa
- Max speed: 50-200mm/s (lubricated condition)
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 70℃
- Body material: Aluminum alloy (anodized finish)
- Guide rail: Stainless steel with PTFE coating
- Port size: M5×0.8 pneumatic interface
- Weight: 350g ±5% (without accessories)
- Dimensions: 120mm(L) × 42mm(W) × 30mm(H)
- Mounting: 4×M4 threaded holes (6mm depth)
- Seals: NBR standard (FKM available for high-temp)
- ISO compatibility: Compliant with ISO 15552 mounting
Precision parallel gripper with integrated hardened guide rails for zero-play linear motion. Features dual-channel air control for independent grip force adjustment. Anti-corrosion treatment makes it suitable for cleanroom environments (ISO Class 5 compatible). Includes built-in shock absorption at stroke ends.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Micro-motor assembly stations
- Optical lens handling systems
- Battery cell sorting robots
Operation tip:
Achieve optimal grip stability by maintaining 0.3-0.5MPa air pressure and
applying silicone-free lubricant every 500,000 cycles. Avoid lateral torque
exceeding 0.5Nm during workpiece handling.
- Use with AIRTAC MPA-L10 magnetic sensor for position feedback
- Compatible with AGP10 series gripper pads
- Recommended tubing: PU04-02 (4mm OD, 2mm ID)
| Property | Property Value |
|---|---|
| sku | HFTKL10F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <8mm> |
