Airtac HFTKL Guided Parallel Type Pneumatic Gripper HFTKL16B
Type: Rail-Guided Parallel Pneumatic Gripper
Brand: AirTAC
Series: HFTKL
AirTAC HFTKL16B Guided Parallel Pneumatic Gripper Specifications
- Model: HFTKL16B
- Type: Guided parallel gripper (double-acting)
- Gripping force: 30N per finger @ 0.6MPa
- Stroke per finger: 8mm (total 16mm opening)
- Operating pressure: 0.2-0.8 MPa
- Guide rail type: Dual linear ball bearings
- Repeat accuracy: ±0.02mm
- Port size: M5 (1/8")
- Material: Aluminum alloy body, hardened steel guide rails
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Compatible rail lengths: 40-200mm (customizable)
- Weight: 320g ±5g
- Dimensions (L×W×H):
76mm (length when closed) × 34mm × 40mm
Expanded length: 92mm (fully open)
Precision parallel gripper with integrated linear guides, designed for high-precision part handling. Features zero-backlash motion through preloaded ball bearings and dual piston drive for symmetrical force distribution. Anodized surface treatment enhances corrosion resistance in industrial environments. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication (optional).
- CNC machine tool part loading/unloading
- Precision component assembly in electronics manufacturing
- Cartesian robot end effectors
- Medical device packaging systems
- Optical lens handling systems
Operational note:
Maintain 0.5-1mm clearance between fingers and workpiece during initial positioning.
For maximum service life, relubricate guide rails every 500,000 cycles using lithium soap grease.
- Max lateral load: 15N
- Max moment load: 1.2N·m
- Response time: 50ms (open-close cycle @ 0.5MPa)
- Air consumption: 4.5cm³/cycle
| Property | Property Value |
|---|---|
| sku | HFTKL16B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | 12mm |
