Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ10
$130.70
Regular price
$138.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFTZ10
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Integrated monolithic linear guide mechanism ensures high rigidity and precision;
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
Operation tip:
For delicate objects, use 0.3-0.5MPa pressure with speed control dials set to 30-40% opening.
Apply light machine oil (ISO VG32) to guide rails every 50,000 cycles.
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ10 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ10
- Type: Guided parallel gripper (double rail structure)
- Gripping force: 14-80N (adjustable via air pressure)
- Stroke per finger: 5mm standard (2.5-10mm customizable)
- Operating pressure: 0.15-0.7 MPa
- Rail type: Precision linear guide with hardened steel balls
- Repeat accuracy: ±0.02mm
- Operating temperature: -10℃ to 70℃
- Port size: M5x0.8 (dual ports for push/pull action)
- Body material: Anodized aluminum alloy (A6063)
- Seal material: NBR rubber with silicone grease coating
- Speed adjustment: Built-in flow control valves (0-120mm/s)
- Mounting: 4x M3 threaded holes (bottom/side mounting)
- Protection rating: IP40 (dust resistant)
- Weight: 450g ±5% (including accessories)
- Dimensions: 80mm(L) × 40mm(W) × 34mm(H)
High-precision parallel gripper featuring dual hardened linear guides for smooth operation and anti-torsion stability. The T-slot design allows flexible jaw customization and rapid tooling changes. Optimized air chamber design ensures consistent gripping force across full stroke range.
Typical Applications:
- PCB component insertion in SMT lines
- Precision parts transfer in watch assembly
- Medical device handling with cleanroom compatibility
- Cartesian robot end-effectors for small parts sorting
- Optical lens positioning systems
Operation tip:
For delicate objects, use 0.3-0.5MPa pressure with speed control dials set to 30-40% opening.
Apply light machine oil (ISO VG32) to guide rails every 50,000 cycles.
Accessory options:
- Custom jaw plates (aluminum/stainless steel/POM)
- Magnetic sensor kit (M9PV series compatible)
- Anti-vibration mounting brackets
- ESD-safe version available (surface resistance 10⁶-10⁹Ω)
| Property | Property Value |
|---|---|
| sku | HFTZ10 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
