Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ16
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ16 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ16
- Type: Guided parallel gripper (double-acting)
- Bore size: Φ16mm
- Stroke range: 5-30mm (customizable)
- Gripping force: 16N @0.1MPa
- Operating pressure: 0.1–0.7 MPa
- Guide type: Dual linear ball bearing rails
- Repeat accuracy: ±0.02mm
- Material: Aluminum alloy body, hardened steel guides
- Surface treatment: Anodized (RAL 5015 optional)
- Weight: 0.45kg (bare gripper)
- Dimensions: 120mm(L) × 52mm(W) × 42mm(H)
- Operating temperature: -10℃ to 70℃
- Lubrication: Pre-lubricated (Molykote 33M)
- Mounting options: Side/end mounting holes (M4×0.7)
- Air connection: M5×0.8 dual ports
Precision-guided parallel gripper featuring zero backlash motion and IP54 protection rating. The dual linear ball bearing system ensures smooth operation with 1.5 million cycle lifespan. Includes replaceable polyurethane jaw pads and magnetic sensor slots (inductive type compatible). Requires 5μm filtered air.
- PCB component insertion machines
- Micro-motor shaft handling systems
- Pharmaceutical blister packaging lines
- Watch movement assembly stations
- Optical lens sorting mechanisms
Operation tip:
Maintain 0.3-0.5MPa working pressure for optimal grip force/response balance.
Use shock absorbers when cycling >60 times/minute. Align workpiece center
within ±1.5mm of jaw midpoint.
| Property | Property Value |
|---|---|
| sku | HFTZ16 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
