Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ25
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ25 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ25
- Type: Guided parallel gripper (dual sliding rail)
- Gripping force: 25N @0.5MPa (adjustable via pressure)
- Max stroke: 8mm (±4mm)
- Operating pressure: 0.1-0.7MPa
- Rail type: Precision hardened steel guide
- Repeatability: ±0.02mm
- Cylinder bore size: Ø25mm
- Temperature range: -10℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Seal material: NBR rubber
- Port size: M5×0.8 (standard), G1/8 optional
- Weight: 420g ±10g
- Dimensions: 78mm(L) × 42mm(W) × 30mm(H)
- Mounting pattern: 4×M4 threaded holes (8mm spacing)
- Max gripping speed: 100mm/s
- Air consumption: 4.5cm³/stroke
Industrial-grade parallel gripper with hardened dual rails for precision linear motion, featuring anti-vibration design for high-speed operations. The T-slot mounting surface allows tooling plate integration, while the symmetrical structure enables mirrored installations. Requires ISO 8573-1 class 3 filtered air.
- PCB component insertion machines
- Automated robotic assembly lines
- CNC machine tool loading/unloading
- Pharmaceutical blister packaging
- Micro-motor shaft handling
Maintenance tip:
Apply light grease (ISO VG10 grade) to guide rails every 50,000 cycles.
Avoid lateral overload beyond 15N to prevent rail deformation.
| Property | Property Value |
|---|---|
| sku | HFTZ25 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
