Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ32
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ32 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ32
- Type: Guided parallel gripper (dual-action)
- Gripping force: 120N (closed)/100N (open)
- Stroke per jaw: ±10mm
- Guide mechanism: Precision linear rail system
- Operating pressure: 0.1-0.7 MPa
- Actuation type: Double-acting pneumatic
- Repeat accuracy: ±0.02mm
- Port size: PT1/8 (G1/8 optional)
- Body material: Anodized aluminum alloy
- Rail material: Hardened steel (HRC58-62)
- Seal material: NBR rubber
- Temperature range: -10℃ to 80℃
- Protection rating: IP54
- Weight: 1.8kg ±5%
- Dimensions: 200mm(L) × 75mm(W) × 45mm(H)
High-precision guided gripper with integrated linear rails ensures minimal angular deviation during operation. Features wear-resistant hardened steel guides and optimized air chamber design for rapid response (opening/closing time <0.5s at 0.5MPa). Includes adjustable mechanical stoppers for stroke limitation.
- Robotic end-effector tooling for CNC machine tending
- Precision component assembly in electronics manufacturing
- Automated packaging line part handling
- Medical device production with cleanroom compatibility
- Glass panel transfer systems
Installation note:
Ensure rail alignment within 0.1mm/m using precision level during mounting.
Lubricate guide rails with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3-0.5μm filtered air supply with 20-30% relative humidity.
| Property | Property Value |
|---|---|
| sku | HFTZ32 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <32 mm> |
| Stroke | 22mm |
