Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ6B
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ6B Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ6B Series
- Type: Guided parallel gripper with integrated linear guide rails
- Bore size: Φ6mm (multiple jaw sizes available)
- Operating pressure: 0.1–0.7 MPa
- Gripping force: 12–84N (adjustable via pressure regulation)
- Stroke per jaw: 2–8mm (model-specific variants)
- Repeat accuracy: ±0.02mm
- Actuation: Double-acting (air required for both open/close)
- Port size: M5×0.8 (dual ports for rapid response)
- Material: Anodized aluminum body, hardened steel guide rails
- Seals: NBR standard (FKM available for high-temp versions)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Weight: 0.65kg (bare gripper), 0.82kg with standard jaws
- Dimensions: 85mm(L) × 32mm(W) × 25mm(H) (base unit)
- Guide type: Precision ball bearing linear guides
- Shock resistance: 15G acceleration (3ms duration)
- Mounting: 4×M4 threaded holes (ISO9409-1 compliant)
- Protection rating: IP54 (standard), IP67 optional
Industrial-grade parallel gripper featuring dual linear guides for exceptional rigidity and alignment stability during high-speed operations. The HFTZ6B's symmetrical force distribution and anti-rotation design ensure precise centering of workpieces, with optional magnetic sensors for position feedback. Optimized flow paths reduce air consumption by 25% compared to previous generations.
- PCB component insertion machines
- Automotive fuel injector assembly
- Pharmaceutical blister packaging
- SCARA robot tool changers
- Optical lens polishing systems
- Battery cell stacking automation
Operational note:
For maximum service life, use filtered air (5μm+coalescing filter) and lubricate guide rails monthly with ISO VG32 turbine oil.
Avoid side impacts exceeding 30N during jaw replacement.
| Property | Property Value |
|---|---|
| sku | HFTZ6B |
| Gripper Optional Types | Side-mounted |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
