Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ6F
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ6F Rail-Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ6F
- Structure: Double-acting parallel motion with linear guide
- Bore size: Φ6mm
- Operating pressure: 0.1-0.7 MPa
- Temperature range: -10℃ to 70℃
- Material: Aluminum alloy body, polyurethane seals
- Guide type: Dual linear ball-bearing rail system
- Repeatability: ±0.02mm
- Max stroke per jaw: 5mm (total opening 10mm)
- Gripping force: 6-42N adjustable (at 0.5MPa)
- Weight: 250g ±5%
- Dimensions: 60mm(L) × 32mm(W) × 25mm(H)
- Mounting: Standard M4 threaded holes (4x)
- Air connection: M5 threaded ports (dual side ports)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km travel)
Precision parallel gripper featuring hardened steel linear guides with ball bearing carriages for smooth operation and high moment resistance. The dual-rail design prevents jaw deflection during high-speed cycling (up to 5Hz). Integrated T-slot allows modular tooling plate attachment. Compatible with ISO 9409-1 mounting patterns.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Micro-motor shaft handling systems
- Optical lens assembly automation
- 3C product testing equipment
Operation tip:
For delicate object handling, use pressure regulator with digital gauge (0.01MPa resolution)
and install shock absorbers on cylinder ports to dampen impact at stroke ends.
- Custom jaw lengths available (5-50mm extension plates)
- Optional magnetic sensor slots for position feedback
- High-temp variant (up to 120℃) with fluorocarbon seals
| Property | Property Value |
|---|---|
| sku | HFTZ6F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
