Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ6N
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ6N Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ6N
- Type: Guided parallel gripper (dual-axis linear guide)
- Gripping force: 12-16N adjustable (at 0.5MPa)
- Stroke per jaw: 0-6mm
- Operating pressure: 0.2-0.7 MPa
- Guide rail type: Precision linear ball bearing structure
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy (hard coating)
- Seal material: Heat-resistant NBR
- Port size: M5 × 0.8 (dual ports for push/pull action)
- Speed adjustment: Built-in flow control valves (2×)
- Protection rating: IP54 (standard), IP67 optional
- Mounting holes: 4× M4 threaded (4.5mm pitch)
- Weight: 280g ±5g
- Dimensions: 76mm(L) × 34mm(W) × 28mm(H)
High-precision guided gripper featuring zero-backlash operation and wear compensation mechanism. The dual linear guides ensure parallel jaw movement with minimal angular deviation (±0.1°). Integrated shock absorbers prevent workpiece slippage during high-speed cycling (up to 3 cycles/sec). Compatible with ISO 9409-1 mounting patterns.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Micro-motor shaft assembly systems
- Optical lens handling in cleanrooms
- 3C product testing equipment
- Precision bearing sorting stations
Installation protocol:
Always preload guide rails with 0.05-0.1MPa air pressure before mechanical fastening.
Use shim washers when mounting on uneven surfaces. Lubricate guide rods monthly with
ISO VG32-grade pneumatic oil.
| Property | Property Value |
|---|---|
| sku | HFTZ6N |
| Gripper Optional Types | Through-hole mounting type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
